ASTM B387 0.18mm molybdenum wire for EDM Cutting machine
Product name: ASTM B387 0.18mm molybdenum wire for EDM Cutting machine
Density: 10.2g/cm3
Standard: ASTM B387
Size: Dia0.01~6mm.
Shape: Straight, Coil.
Technology: Powder Metallurgy, Wire Drawing
Characteristic:
Melting Point: 2618 Degrees Celsius
Boiling Point: 5560 Degrees Celsius
Grade:
Mo1, Mo2 ,TZM, MoLa，WMo
Surface: Stretching, Polishing.
Type：
|
Molybdenum Wire Type
|
Diameter(Inch)
|
Tolorance
|
|
Molybdenum Wire for EDM
|
0.007"~0.01"
|
±3%wt
|
|
Molybdenum Spray Wire
|
1/16"~1/8"
|
±1%~±3%wt
|
|
Molybdenum Wire
|
0.002"~0.08"
|
±3%wt
|
|
Molybdenum Wire (Clean)
|
0.006"~0.06"
|
±3%wt
|
Application:
• Electric light source, Electrode, especially for medium speed machine
• Heating elements, High-temperature components
• Wire-electrode cutting
• Spraying for auto parts
Feature:
• High melting point, Low density and Thermal coefficients
• Good thermal conductivity properties and Resistance of high-temperature
• High tensile strength and Low elongation
• Good stability and High precision of cutting
• High speed and Long stable time of processing
• Long lifetime and Non-poisonous
Chemical Composition:
|
Grade
|
The impurity content is not more than %
|
|
Fe
|
Ni
|
AI
|
Si
|
Mg
|
C
|
N
|
O
|
|
Mo1
|
0.01
|
0.005
|
0.002
|
0.01
|
0.005
|
0.01
|
0.003
|
0.008
|
|
Mo2
|
0.01
|
0.005
|
0.005
|
0.01
|
0.005
|
0.01
|
0.003
|
0.02
|
Packing
Plywood case or According to customer requirements
Email: jasontitanium@163.com
Whatsapp/Skype/Wechat/Line: +86-15829508781
